www.cosnet-elevage.fr - 6 - Year 2022 2023 TUBULAR LIVESTOCK EQUIPMENT METAL HAY RACKS ON FEET DOUBLE METAL HAY RACKS Three-side opening. Factory-fitted bottom reinforcement. PRODUCT Three-side opening. Factory-fitted bottom reinforcement. These new-generation double hay racks are designed to open on three sides: the two wide sides and the side opposite the hitch. With a total length of 3 m, these double hay racks are factory fitted with two Ø 60.3 mm bottom reinforcement bars (thickness 3.2 mm). Their structure is hot-dip galvanised after assembly. Their design, incorporating four main 3 mm thick uprights, is very robust. They are factory fitted with: - bottom sheets reinforced by two cones to centre round bales. Ends drilled with several holes to evacuate moisture. - ‘optimum’ roof, with a wide curve to improve the installation of large hay bales and a larger covered surface to better protect them from the rain, - the height of the roof and pads can be adjusted by through bolts, - monoblock hitch panel to reduce assembly time and contribute to the structure’s strength, - Folding tow bar, - 2 Ø 60.3 mm bottom reinforcement tubes (thickness 3.2 mm), - Side reinforcement bars and roof protection kit. Double pasture hay racks are suited to the distribution of hay in large square or round bales in fields. A 1 2 3 RDTC II DOUBLE SELF-LOCKING HEADLOCK HAY RACK Patented elastic spring system. Fitted with quick release polymer tabs and an automatic handle. "Comfort SR self-locking headlock" PRODUCT The double self-locking headlock hay rack is fitted with: - 4 headlock panels using ‘comfort SR’ headlock panel technology, - anti-choke system, - patented elastic spring system, - quick release polymer tabs and automatic handle, - 3.10 m roofing. Designed for hornless herds. Delivered in kit . Type : ‘’Comfort SR’’ self-locking headlock Material : Galvanised steel Model Number of feed spaces Length m Width m Net weight kg Code Unit € Ex. VAT Packing Dealer RDTC II 14 3 2 620 112 10 05 3 RDTLS II DOUBLE FEED PANEL HAY RACK The double feed panel hay rack is fitted with: - 4 reinforced feed panels assembled with notches on the Ø 60.3 mm side rails, connected to an upper bar, - 3.10 m roofing. Designed for horned or hornless herds. Delivered in kit. Type : Feed panels Material : Galvanised steel Model Number of feed spaces Length m Width m Net weight kg Code Unit € Ex. VAT Packing Dealer RDTLS II 14 3 2 480 112 10 03 2 RDTF II DOUBLE TOMBSTONE HAY RACK 3.10 m ‘optimum’ roof. Reinforced tombstones. PRODUCT The double tombstone hay rack is fitted with: - 4 full-access tombstone panels with notches on Ø 60.3 mm side rails, - 3.10 m roofing. Designed for horned or hornless herds. Delivered in kit. Type : Tombstone panels Material : Galvanised steel Model Number of feed spaces Length m Width m Net weight kg Code Unit € Ex. VAT Packing Dealer RDTF II 14 3 2 467 112 10 01 1 A page 7 options
